Installing a home lift involves more planning than a stairlift, but it’s still far less disruptive than most people imagine. In this guide we walk through the full process from initial survey to handover, including building regulations, structural requirements, and typical timelines.
Installation Timeline
| Stage | Duration | Details |
|---|---|---|
| Home survey | 1–2 hours | Specialist assesses your home, measures, and recommends options |
| Building control notification | 1–2 weeks | Building notice submitted before work begins |
| Structural preparation | 0.5–2 days | Cutting and reinforcing floor/ceiling opening |
| Lift installation | 1–5 days | Depends on type: through-floor (1–2), cabin (3–5) |
| Testing and commissioning | Half day | Safety checks, demonstration, user training |
| Building control sign-off | 1–3 weeks after | Inspector visits to confirm compliance |
Total time from order to operational lift is typically 2–8 weeks for through-floor lifts and 6–12 weeks for cabin-style lifts (which often need custom manufacturing).
Structural Requirements
The structural work depends entirely on the type of lift:
- Through-floor lifts — A rectangular opening (roughly 1m x 1.4m) is cut through the ceiling/floor and reinforced with a steel frame. This is the main building work required
- Self-supporting lifts (Stiltz, Lifton) — Only need a ceiling opening for the lift to pass through. No shaft, pit, or load-bearing wall modifications needed
- Hydraulic and traction lifts — Require a lift shaft (which can be built from prefabricated panels), and some models need a small pit (150–200mm deep) at the base
- Pneumatic vacuum lifts — Need a floor opening but no shaft or pit. The tube structure is self-supporting
Building Regulations
Most home lift installations require a building notice to be submitted to your local authority building control department. This is mandatory when the installation involves cutting through a floor. The building control inspector will visit during or after installation to verify the work meets structural and fire safety requirements.
Key regulations that apply:
- BS 6440 — The British Standard for through-floor lifts, covering design, installation, and safety
- EN 81-41 — European standard for enclosed cabin-style home lifts
- Part B (Fire safety) — The ceiling opening may need fire protection, especially if it connects a means of escape route
- Part M (Access) — Relevant if the lift is being installed as part of a wider accessibility adaptation
- UKCA/CE marking — All domestic lifts must carry appropriate certification
planning permission
Most internal home lift installations do not require planning permission. However, you may need it if:
- You live in a listed building — listed building consent may be needed
- You’re in a conservation area and the installation affects the external appearance
- An external lift shaft is being built
- The lift is being installed in a flat within a converted building
Your lift supplier should advise on planning requirements during the survey. If in doubt, check with your local planning authority before committing.
Power and Electrics
Most home lifts plug into a standard 13-amp socket, just like a stairlift. Larger cabin lifts may require a dedicated electrical supply, but this is unusual for residential models. Running costs are very low — typically £30–£50 per year in electricity.
All home lifts should have a battery backup or manual lowering system for power cuts, ensuring no one gets trapped between floors.
Choosing an Installer
- Use a supplier approved by the lift manufacturer — this protects your warranty
- Check for BHTA membership or equivalent trade body registration
- Ask for references from previous home lift installations in your area
- Confirm the quote includes building work, electrical connection, building control fees, and commissioning
- Check aftercare arrangements — who services the lift and how quickly they can respond to callouts
Frequently Asked Questions
How much mess and disruption should I expect?
The main disruption is the floor/ceiling opening, which creates dust and noise for half a day to a day. Good installers will sheet up surrounding areas and vacuum afterwards. Once the opening is prepared, the lift installation itself is relatively clean work. Most people continue living in their home throughout.
Can a home lift be removed later?
Yes. The lift can be removed and the floor opening filled in and reinforced. This restores the property to its original layout, though some cosmetic redecoration will be needed. Many buyers find that home lifts actually add value to their property rather than detract from it.
